can my 4" thick concrete slab hold a hot tub

Updated: March 11, 2025

Author: Mike Day

QUESTION:

We had a 12' X 44' ft. concrete slab attached to our home last year and now have a screen porch at our Florida location.

We would like to put a hot tub on the slab, but can the concrete hold the hot tub that weighs about 5200 pounds with water and 4 people? The size is 89 inches square.

Can my concrete slab hold a hot tub

To determine if a 4-inch thick concrete slab can support a 5,200-pound hot tub (plus additional weight from people), we need to evaluate the load-bearing capacity of the slab.

Learn how to install a concrete slab for a Hot Tub in The Concrete Underground

Key Factors to Consider:

1. Load Distribution

  • If the hot tub has a large footprint, the weight is spread over a greater area, reducing stress on the slab.
  • If the hot tub is small and concentrated, it creates higher pressure on the concrete.

2. Concrete Strength

  • Standard concrete has a compressive strength of 3,000-4,000 psi, but a reinforced slab can handle more.
  • The modulus of rupture (flexural strength) determines its ability to resist cracking.

3. Reinforcement

  • A 4-inch slab without reinforcement is more prone to cracking.
  • Adding rebar (#3 or #4 at 12-inch spacing) or wire mesh significantly improves load distribution and prevents failure.

4. Soil/ Subbase Support

  • A well-compacted gravel base (at least 4-6 inches) improves load distribution.
  • Weak or expansive soil may cause sinking, heaving, or cracking.

Load Calculation for a hot tub on a concrete slab

  • Assume the hot tub is 7 ft x 7 ft (49 square feet).
  • Load per square foot = 5,200 lbs ÷ 49 sq ft ≈ 106 lbs/sq ft
  • If we add 1,000 lbs for people, the total weight = 6,200 lbs, which results in about 127 lbs/sq ft.
  • A typical 4-inch reinforced concrete slab can handle 300-500 lbs/sq ft, assuming proper base preparation.

Final verdict

✅ A 4-inch concrete slab CAN support a 5,200 lb hot tub, provided:

  • It is reinforced with rebar or wire mesh.
  • It has a well-compacted subbase (gravel or crushed stone).
  • The slab is in good condition without major cracks.

⚠ However, for added safety and longevity, it is recommended to:

  • Increase slab thickness to 6 inches (especially for heavier loads).
  • Use a concrete mix of at least 4,000 psi.
  • Add fiber reinforcement or rebar (#4 at 12-inch spacing).

recommended concrete slab design for a hot tub

Detailed Reinforcement Design & Concrete Mix for Hot Tub Slab

To safely support a 5,200 lb hot tub (plus ~1,000 lbs from people), the concrete slab must be properly reinforced and designed.

Here’s the recommended design:

1. Slab Thickness & Reinforcement

  • Thickness: 6 inches (recommended for long-term durability)
  • Reinforcement: #4 rebar (½ inch diameter) at 12-inch spacing, both directions
  •  Place 2 inches from the bottom of the slab using rebar chairs.
  • OR: Use 6x6 W2.9xW2.9 wire mesh (minimum) if rebar is unavailable.
  • Consider adding fibers to reduce shrinkage cracks.

2. Subbase Preparation

  • 4-6 inches of compacted crushed stone or gravel (e.g., ¾” crushed rock)
  • Compact in 2-inch layers using a plate compactor.
  • If soil is weak, increase the base to 8 inches.

3. Concrete Mix Design (4,500 psi)

For a durable and strong slab, use high-strength concrete (4,500 psi or higher).

Concrete Mix Ratio (by volume):

  • 1 part cement (Portland Type I or II)
  • 2 parts sand
  • 3 parts coarse aggregate (¾" crushed stone)
  • Water-to-cement ratio: 0.45 (adjust as needed for workability)
  • Air entrainment: 5-7% (if exposed to freezing conditions)
  • Optional: Add fiber reinforcement (e.g., synthetic microfibers for crack resistance)

4. Placement & Curing

  • Pour concrete in one continuous operation.
  • Use a vibrator to remove air pockets and ensure consolidation.
  • Screed and finish with a bull float, but do not overwork the surface.
  • Curing: Cover with plastic or use a curing compound for 7 days to prevent cracks.

5. Expansion Joints & Drainage

  • Control Joints: Cut joints every 4-5 feet (~¼ of slab thickness deep)
  • Drainage: Ensure the slab is sloped (¼” per foot) to prevent water pooling.

Final Verdict

✔ A 6-inch reinforced slab with proper base and concrete mix will easily support your hot tub.
✔ If using a 4-inch slab, it must have high-strength concrete and rebar to avoid cracking over time.

To learn how to install a concrete slab for a hot tub, patio, shed, or a garage, join my training in The Concrete Undergroud
